MODULE Wide-temp CN

SATA DOM Module · Wide-temp · CN

SLC Chip · Compatible with Kontron (Germany)

Operating temperature -40℃~85℃
Capacity 8GB-32GB
Read Speed 100MB/s
SATA DOM Module · Wide-temp · CN

Key facts

What industrial buyers usually need to know first — before diving into the full datasheet.

5-year supply · 12-month EOL notice

Qualified SKUs stay available for long-lifecycle equipment — you get advance notice before any discontinuation.

MOQ from 1 pc

Prototype and repair lots without large inventory lock-in — then scale to production.

BOM review & firmware fit

We help match incumbent PNs, validate drop-in paths, and can adjust firmware / grade when the catalog needs a tweak.

5-year warranty · 4–8 weeks lead time

Stable production scheduling with a typical 4–8 weeks lead time once configuration and forecast are agreed.

MOQ From 1 pc
Standard lead time 4–8 weeks (typical; confirm with sales for your configuration)
Warranty 5 years (see /warranty for tier details)
Supply commitment Minimum 5 years for qualified SKUs · 12-month EOL notice
Engineering support BOM review, drop-in / fit checks, firmware and temperature-grade adaptation on request
Samples Available on request

Overview

Equipped with high-reliability SLC chips, this product is specifically designed for industrial computers and embedded systems. It is fully compatible with Germany's Kontron KSSD S-DOM series products, supports stable operation within a wide temperature range of -40℃ to 85℃, and serves as an ideal replacement option.

Specifications

Interface SATA II
Connector Samtec SQT-104-01-L-D
Capacity Options 8GB/16GB/32GB
Operating temperature -40℃~85℃
Storage temperature -45℃~90℃
Read Speed Up to 100MB/s
Write Speed Up to 80MB/s
Flash Type SLC
Compatibility Compatible with Kontron KSSDS-DOM series products, direct replacement available
System Compatibility Compatible with multiple systems including VxWorks, Linux, Windows XP, etc.
Reliability Standard Environmental testing and reliability meet relevant specification requirements
Warranty Period 5-year warranty service

Orderable part numbers

Handbook PNs for this page. Confirm package, temperature bin, and speed grade before production.

Part numberGradeSummary
YIDP008SAS-D Wide-temp 8GB · -40℃~+85℃
YIDP016SAS-D Wide-temp 16GB · -40℃~+85℃
YIDP032SAS-D Wide-temp 32GB · -40℃~+85℃

Compliance & Standards

Quality and release processes for Loongtion industrial memory and storage. Formal certificates and scope statements are available in the quotation pack on request.

Quality management system

  • ISO 9001:2015 certified (GB/T 19001-2016)
    Quality management systems — Requirements. Certified quality system covering semiconductor integrated circuits and solid-state storage modules (design, development, production, and technical support) and hybrid integrated circuits (design, development, and technical support).
  • Conforms to GJB 9001C—2017
    Quality management systems — Requirements. Quality system practices conform to GJB 9001C for the same scope: semiconductor integrated circuits and solid-state storage modules (design, development, production, and technical support) and hybrid integrated circuits (design, development, and technical support).

Product & interface standards

This catalog SKU follows the industry specifications that define its form factor and host interface.

  • Module / DOM host interfaces
    Module pinout and host protocol follow the applicable SATA or other interface specification stated on the datasheet.
  • Serial ATA (SATA)
    SATA interface timing and command set follow the SATA revision applicable to the listed SKU (commonly SATA III).

Grade wording: Product grade definition.

Key highlights

High-performance SATA DOM, Perfectly Compatible with Kontron Products

  • Fully Compatible with KSSD
    S-DOM Series
  • Standard SATA Interface
    Plug and Play
  • High Durability SLC NAND
    Flash Longer Lifespan
  • Read 100MB/s, Write 80MB/s
  • High-Quality Replacement

Typical applications

Compact SATA Disk-on-Module for embedded hosts that need boot or OS storage without a 2.5\" bay.

Industrial PC / embedded motherboard boot

7-pin SATA DOM as the system disk for industrial PCs, panel PCs and embedded motherboards.

Legacy platform replacement

Drop-in alternative for Kontron-class SATA DOM modules in long-lifecycle equipment.

Compact automation controllers

Space-constrained PLC / motion controllers that cannot fit a full-size SSD.

Series

  • SATA DOM
    China-localized industrial SATA DOM — SLC 8/16/32 GB, −40~85°C.

Frequently asked questions

What is the operating temperature range of the Loongtion SATA DOM?

YIDP (SLC) / YIDQ (pSLC) series is rated -55C to +105C extreme temperature - competitors (Innodisk, Kontron, Apacer) stop at -40C to +85C.

What are the key specifications?

SATA III 6.0 Gb/s (~560/420 MB/s read/write), 8GB-256GB, 36-pin 7+15 vertical connector, ~26.7 x 20.3 x 8.8 mm, 1,500G shock rating. pSLC endurance ~100,000 P/E cycles.

Is this a drop-in replacement for Innodisk/Kontron/Apacer SATA DOM?

Yes - YIDP/YIDQ maps to Innodisk SATADOM, Kontron KSSDS/KCDSK, and Apacer SDM families with a 15C-25C temperature advantage. See the cross-reference catalog.

What is the lead time?

4-8 weeks for standard industrial orders.
