Rugged USB Storage Module
All-Metal Shielding · Vibration & Shock Resistant
Key facts
What industrial buyers usually need to know first — before diving into the full datasheet.
5-year supply · 12-month EOL notice
Qualified SKUs stay available for long-lifecycle equipment — you get advance notice before any discontinuation.
MOQ from 1 pc
Prototype and repair lots without large inventory lock-in — then scale to production.
BOM review & firmware fit
We help match incumbent PNs, validate drop-in paths, and can adjust firmware / grade when the catalog needs a tweak.
5-year warranty · 4–8 weeks lead time
Stable production scheduling with a typical 4–8 weeks lead time once configuration and forecast are agreed.
| MOQ | From 1 pc |
|---|---|
| Standard lead time | 4–8 weeks (typical; confirm with sales for your configuration) |
| Warranty | 5 years (see /warranty for tier details) |
| Supply commitment | Minimum 5 years for qualified SKUs · 12-month EOL notice |
| Engineering support | BOM review, drop-in / fit checks, firmware and temperature-grade adaptation on request |
| Samples | Available on request |
Overview
Rugged USB Storage Module, specifically designed for aerospace and extreme environments, adopts a full metal shielded enclosure and Rugged aviation connector, features superior vibration and shock resistance, and supports stable operation in an ultra-wide temperature range of -55℃ to 105℃.
Specifications
| Interface | USB 2.0 |
|---|---|
| Connector | Ruggedized Aviation Connector |
| Capacity Options | 8GB~256GB (pSLC/TLC) |
| Operating temperature | −55°C to +125°C (pSLC) / −40°C to +85°C (TLC) |
| Storage temperature | -45℃~90℃ |
| Read Speed | Up to 40MB/s |
| Write Speed | Up to 30MB/s |
| Flash Type | pSLC (8GB-64GB) / TLC (64GB-256GB) |
| Shielding Design | Full Metal Sealing, High Protection Grade |
| High Quality | Equipped with self-packaged wide-temperature grade eMMC chips, high-quality core solution |
| Reliability Standard | Environmental testing and reliability meet relevant specification requirements |
| Warranty Period | 5-Year Warranty Service |
Orderable part numbers
Handbook PNs for this page. Confirm package, temperature bin, and speed grade before production.
| Part number | Grade | Summary |
|---|---|---|
YIDM064UTET-D |
Wide-temp | 64GB · TLC · -40℃~+85℃ |
YIDM128UTET-D |
Wide-temp | 128GB · TLC · -40℃~+85℃ |
YIDM256UTET-D |
Wide-temp | 256GB · TLC · -40℃~+85℃ |
YMDM008UTES-D |
GJB-STD | 8GB · pSLC · -55℃~+125℃ |
YMDM032UTES-D |
GJB-STD | 32GB · pSLC · -55℃~+125℃ |
YMDM064UTES-D |
GJB-STD | 64GB · pSLC · -55℃~+125℃ |
Cross-references
No verified one-to-one vendor PN is published for this SKU yet. Browse the part-number catalog or contact engineering for BOM matching.
Compliance & Standards
Quality and release processes for Loongtion industrial memory and storage. Formal certificates and scope statements are available in the quotation pack on request.
Quality management system
-
ISO 9001:2015 certified (GB/T 19001-2016)
Quality management systems — Requirements. Certified quality system covering semiconductor integrated circuits and solid-state storage modules (design, development, production, and technical support) and hybrid integrated circuits (design, development, and technical support).
-
Conforms to GJB 9001C—2017
Quality management systems — Requirements. Quality system practices conform to GJB 9001C for the same scope: semiconductor integrated circuits and solid-state storage modules (design, development, production, and technical support) and hybrid integrated circuits (design, development, and technical support).
Environmental methods (GJB-STD)
For Extreme-temp / GJB-STD SKUs, environmental planning and screening reference the following methods. This is not a claim of third-party product certification under these standards.
-
GJB 150A (aligned with MIL-STD-810 methods)
Military equipment laboratory environmental test methods. GJB-STD SKUs are designed and screened with reference to GJB 150A; it is the Chinese military counterpart commonly mapped to MIL-STD-810 style environmental methods.
Product & interface standards
This catalog SKU follows the industry specifications that define its form factor and host interface.
-
Module / DOM host interfaces
Module pinout and host protocol follow the applicable SATA or other interface specification stated on the datasheet.
Grade wording: Product grade definition.
Key highlights
Reinforced Design, Adapt to the Most Extreme Operating Environments
-
Aviation Connector Interface
Reliable Connection
-
360° Full Metal Sealed
Enclosure Anti-Electromagnetic Interference
-
Universal USB Interface
Wide Compatibility
-
Passed Strict Vibration
and Shock Tests
- High Quality
Typical applications
Rugged USB module with industrial connector for field data exchange and portable logging.
Field data offload
Secure hand-off of logs and configuration between industrial hosts and service laptops.
Vehicle / outdoor terminals
Wide-temperature USB storage for terminals exposed to outdoor or in-vehicle climates.
Maintenance and provisioning
Firmware images, maps and recipes carried on a ruggedized USB key for service teams.
Related products
SATA DOM Module · Wide-temp
- 36-pin Dual In-line Package
- SATA III Interface
- Compatible with VxWorks
Data Recording Module
- Supports synchronous
- Independent offline working
- Industrial-grade storage
LGA Storage Module
- 48pin Surface-mount Design
- SATA III Protocol
- Capacities ranging
PATA DOM Module
- Fully Compatible
- Traditional PATA Interface
- Plug-in Design
Product grade definition
What "GJB-standard" means on this website
How we use this label on our site: reliability tier, documentation, and use-case boundaries.
On this website, "GJB-standard" refers to a higher-reliability product tier within our portfolio. It emphasizes environmental robustness, reliability validation, and manufacturing/quality controls that exceed typical consumer-grade products and, where stated for a given SKU, exceed the baseline of our standard Industrial offerings. This label is used to reduce confusion between product grades and does not constitute a representation that any product is suitable for any particular application, including military end-use.
Any differences versus Industrial are defined per SKU in the applicable datasheet / technical documentation (for example: wider operating temperature, stricter mechanical/climatic stress validation, tighter consistency and traceability controls, where applicable).
GJB (if referenced for a product): applicable clauses, test items, and whether requirements apply to product specifications versus management system certification scope are governed solely by that product's technical documentation and, where applicable, the scope of certification. For additional documentation, please contact us (additional materials may be provided under NDA or after customer qualification, as applicable).
